8" Axial Explosion-Proof (EX) Metal Blower w/ Canister & 25’ Statically Conductive Ducting, 57 lbs. (220V AC/50 Hz). Does NOT meet CSA C22.2 No. 113 requirements. (9514-06E)

This blower features an electric, explosion-proof, single-phase motor that is UL listed and includes a NEMA rated 115V plug. It features tough steel construction and meets Class I, Divisions 1 and 2, Groups C and D and Class II, Divisions 1 and 2, Groups F and G Hazardous Location Requirements.* NOTE: Explosion-proof blowers require an explosion-proof socket.

1/3 HP
Available in both US and International wiring configurations
Available as blower only or complete unit with 15’ (4.57 m) or 25’ (7.62 m) of ducting and storage
Certified to CSA Standard C22.2 No 113.
Epoxy powder-coated in "safety orange"
18-gauge cold rolled steel housing
14-gauge steel enclosed panel
Welded motor mount construction
3-ply rubber handle
Made in USA
Glass reinforced polypropylene (PPG) six blade fan with aluminum hub
Ducting is black single ply, neoprene coated, vinyl/polyester material, temperature resistant up to 250° F (121.1° C)
Meets Class I, Divisions 1 and 2, Groups C and D and Class II, Divisions 1 and 2, Groups F and G Hazardous Location Requirements

Power Tools Amps: 1.2 A
PPE Standards: N/A
Blower Motor HP: 1/3
Blower CFM: 890
Blower M3 per Hour: 1512
Blower M3 per Min: 25
Blower CFM 1 Bend Duct: 825
Blower M3 per Hour 1 Bend Duct: 1402
Blower CFM 2 Bend Duct: 770
Blower M3 per Hour 2 Bend Duct: 1308
Blower Electrical Current: 220V AC, 50 Hz
Blower Duct: 25'/7.6m
Blower Configuration: EX
Blower Housing: Metal
Blower Design: Axial
Blower Phase: Single
Fit for Hazardous Locations: Yes
Blower Respiratory EU 220V: Yes
Outdoor Rated: N/A
Port Size: 8"
