6' ViewPack® Tie-back Energy Absorbing Lanyard, Single-leg with Steel Snap Hooks (82562)

Features

• Constructed with jacketed double-layer polyester webbing for added strength and abrasion resistance
• Features Tie-back D-ring for wrap-around anchoring and eliminates the need for a separate tie-off anchor point.
• Energy absorber features patented ViewPack® cover with inspection window
• ViewPack® cover also features WrapPack label protection
• Includes alloy steel snap hooks for harness attachment and D-ring anchorage connection
• Complies with ANSI Z359.13-2013


Material Specifications

• Webbing: Polyester; 5,000 lb min. static strength
• Energy Absorber: Polyester tear-away
• Connectors: Plated alloy steel; 5,000 lb min. static strength with 3,600 lb gate strength
• D-ring: Plated alloy steel; 5,000 lb min. static strength

Performance Specifications

• Static Strength: 5,000 lb min.


• ANSI Lanyard Class: 6' free fall


• Max. Arrest Distance: 48"


• Avg. Arrest Force: 900 lb


• Max. Arrest Force: 1,800 lb


• ANSI User Capacity: 130 to 310 lb max.


• OSHA User Capacity: 130 to 310 lb max.

Compliant With:
